STRAIGHT TRUCK SCALES AIR-WEIGH... GET ON-BOARD!
NEVER OVER OR UNDER LOAD AGAIN
Operate efficiently and never over or under load your truck with Air-Weigh’s LoadMaxx or QuickLoad Truck on-board scale. Accurate and durable, these scales are perfect for any straight or work truck, from commercial side-loading refuse trucks to delivery vans to cement trucks.
SAVE TIME & MONEY
An investment that pays for itself and then quickly begins to pay towards the bottom line going forward.
EASY TO USE
Air-Weigh scales are intuitive with a simple read-out and built in alarms so drivers never over or under load.
REDUCE LIABILITY
Overloaded trucks are unsafe and require more maintenance. Air-Weigh scales circumvent safety concerns and reduce vehicle maintenance costs.
straight TRUCK SCALES COMES WITH ALL THE FEATURES YOU NEED
Our Truck Scales come with all of the features you need to manage the weights of your entire fleet easily.
- Measures Steer, Drive, GVW and Net Payload
- Supports air ride and most mechanical suspensions
- Dual point calibration – empty and fully loaded
- Pin protected settings
- Alarm Outputs: Two, both with warning and overweight thresholds
- Temperature and altitude Compensation
- Optional printer for instant weight receipts (RS-232)
- Communicate weight data back to the office with the LoadMaxx option
- View weights on any smart device with the LoadMaxx App
- Integration options with third party on-board computer systems
WHICH straight TRUCK SCALE IS RIGHT FOR you?
We have created two on-board scales for straight trucks so that drivers and business owners have a choice. Our economical QuickLoad Straight Truck scale is perfect for owner-operators who simply want to know their truck’s weight and get on the road. The full-feature LoadMaxx Straight Truck scale is your fleet’s solution. If you are looking for a scale that will integrate with your existing onboard computer system and pair with our LoadMaxx app, the LoadMaxx Straight Truck scale is right for your business.
LOADMAXX
TECH SPECS & FAQS
LOADMAXX FEATURES
Measures steer, drive, GVW, and Net Payload
Supports air ride and most mechanical suspensions
Dual point calibration – empty and fully loaded
Pin protected settings
Alarm Outputs: Two, both with warning and overweight thresholds
Temperature and Altitude Compensation
Optional printer for instant weight receipts (RS-232)
Third party on-board computer integration (view partners)*
*Advanced communication features included only with LoadMaxx
TECHNICAL SPECS FOR LOADMAXX
Industry-leading accuracy
Operating Temperatures: 0 deg to +50 deg C; 32 deg to + 122 deg F
J1708 Interface
J1939/CAN Interface
Units: Pounds or Kilograms; user selectable
Power: 9 to 32 V dc
Languages: English, Spanish, French and German
Installation option: In-dash or mounting pod
LOADMAXX INSTALLATION INSTRUCTIONS AND USER GUIDE
We have manuals and videos with installation information as well as user instructions for all Air-Weigh products. See below for the LoadMaxx Truck links:
LoadMaxx Installation Guide for Trucks and Tractors with Air Pressure Drive
LoadMaxx User Guide for Trucks
I NEED HELP TROUBLESHOOTING MY SCALE
We recommend you contact our customer support team at 888-459-3247 anytime you need help with your scale.
HOW DO I USE MY SCALE?
In order to get an accurate weight with your on-board scale, park your vehicle on level ground with the engine running and the brakes released. For air ride, briefly deflate the air suspension and inflate to ride height. Weights are displayed on the easy-to-read digital display.
HOW DOES MY SCALE WORK?
Air-Weigh scales work on all air ride suspensions and most trucks with mechanical or spring-based suspensions. Air pressure sensors measure pressure in the air springs, and deflection sensors measure flex of axles or beams for mechanical suspensions. The scale converts the sensor measurements into accurate on-the-ground weights.
QUICKLOAD
TECH SPECS & FAQS
QUICKLOAD FEATURES
Measures steer, drive, GVW, and Net Payload
Supports air ride and most mechanical suspensions
Dual point calibration – empty and fully loaded
Pin protected settings
Alarm Outputs: Two, both with warning and overweight thresholds
Temperature and Altitude Compensation
Industry-leading accuracy
Operating Temperatures: 0 deg to +50 deg C; 32 deg to + 122 deg F
Units: Pounds or Kilograms; user selectable
Power: 9 to 32 V dc
Languages: English, Spanish, French and German
Installation option: In-dash or mounting pod
TECHNICAL SPECS FOR quickLOAD
Industry-leading accuracy
Operating Temperatures: 0 deg to +50 deg C; 32 deg to + 122 deg F
Units: Pounds or Kilograms; user selectable
Power: 9 to 32 V dc
Languages: English, Spanish, French and German
Installation option: In-dash or mounting pod
QUICKLOAD INSTALLATION INSTRUCTIONS AND USER GUIDE
I NEED HELP TROUBLESHOOTING MY SCALE
We recommend you contact our customer support team at 888-459-3247 anytime you need help with your scale.
HOW DO I USE MY SCALE?
In order to get an accurate weight with your on-board scale, park your vehicle on level ground with the engine running and the brakes released. For air ride, briefly deflate the air suspension and inflate to ride height. Weights are displayed on the easy-to-read digital display.
HOW DOES MY SCALE WORK?
Air-Weigh scales work on all air ride suspensions and most trucks with mechanical or spring-based suspensions. Air pressure sensors measure pressure in the air springs, and deflection sensors measure flex of axles or beams for mechanical suspensions. The scale converts the sensor measurements into accurate on-the-ground weights.
Eugene, Oregon
WE MAKE IT ALL RIGHT HERE
Air-Weigh is an American-owned company making our products right here in the USA. Every one of our scales is developed, manufactured, and supported here in America. So, if you’re looking for American Made, you can’t get better than Air-Weigh!
We are also proud members of the Truckload Carriers Association and the Technology Maintenance Council.
Transform Your Weighing Experience
OUR SALES & SUPPORT TEAMS ARE HERE TO HELP!
Call or email us and we’ll find the on-board scale solution that’s right for you. From scale selection and installation through calibration and best practices, we are with you for the long haul!
